2-PC Side Entry Floating Ball Valve, F304, DN15, PN64, API 6D, RF
China 2-PC Side Entry Floating Ball Valve Manufacturer Oudian Offers Floating Ball Valve, 2-PC, Side Entry, API 6D, DN15, PN64, RF, FF EN558-1/line 2.
Design Standard: API 6D/API 608
Fire safe: API 607/6FA
Pressure temperature Ratings: ASME B16.34
Size Range: 2” to 48” （DN50-DN1200）
Port: full bore or reduced bore
Pressure Range: 150LB to 2500LB
End Connections: Flanged RF, RTJ, Butt Weld
Ball Type: Forged solid ball
Flanged End Dimensions: ASME B16.5 (24” and below), ASME B16.47 Series A or B (above 24”)
Butt Weld End Dimensions: ASME B16.25
Face to Face Dimensions: ASME B16.10
Inspection and Testing: API 6D
Body materials: A105/A105N, F304, F316, F316L, F51, F53, F55, C95800, UNS N08825, UNS N06625.
Seat Materials: PTFE, RPTFE, DEVLON, NYLON, PEEK, metal seated with TCC/STL/Ni.
